June 28, 2022

MINEBEA MITSUMI Inc.

ABLIC Launches the S-82R1 and S-82S1 Series of 1-cell Battery Protection ICs
with Battery Voltage Monitoring Pin

- Battery Voltage Monitoring Pin (BS Pin) Provides Accurate Voltage Monitoring -

image : S-82R1 and S-82S1 Series
logo : MinebeaMitsumi Group Green Products

MinebeaMitsumi Group
Green Products

ABLIC (President: Nobumasa Ishiai, head office: Minato-ku, Tokyo hereinafter "ABLIC"), a group company of Minebea Mitsumi Inc. today launched the S-82R1 and S-82S1 Series of 1-cell battery protection ICs using a battery voltage monitoring pin (BS pin) to ensure accurate battery voltage monitoring.

The new S-82R1 and S-82S1 Series launched today are 1-cell lithium-ion battery protection ICs equipped with a battery voltage monitoring pin (BS pin) to provide the following features:

(1) Accurate battery voltage monitoring even during fast charging is ensured by the battery voltage monitoring (BS) pin. (A feature common to all Series.)

(2) Industry's top class charge-discharge overcurrent detection voltage accuracy of ±1.0mV (S-82S1 Series) and ±1.5mV (S-82R1 Series) reduce variations in overcurrent detection while lowering resistance in current detection resistance.

(3) Overheat protection can be provided by connecting an NTC thermistor to the thermistor connection pin (TH pin). (A feature common to all Series.)

These features enable accurate battery voltage monitoring even during fast charging, lower resistance in current detection resistance to reduce heat generation in the protection circuit board and implement overheat protection functionality to significantly improve product safety.

Example of protection circuits using the S-82R1/S-82S1 Series

Example of protection circuits using the S-82R1/S-82S1 Series

Major Features

  1. Accurate battery voltage monitoring even during fast charging through use of battery voltage monitoring pin!
  2. Industry's top class high accuracy overcurrent detection voltage of ±1mV! (S-82S1 Series)
  3. Overheat protection enabled by connecting an NTC thermistor!

Application Examples

Lithium-ion rechargeable battery packs, lithium polymer rechargeable battery packs

Examples of products using these ICs

Smartphones, tablet PCs, smartwatches, etc.

image : Smartphones, tablet PCs, smartwatches, etc.

S-82R1/ S-82S1 Product details

Website

https://www.ablic.com/Open in a new window

Contacts ABLIC Inc. Masae Onuma
E-mail: pr@ablic.com
https://hub.ablic.com/en/pr-inquiry?rf=supportOpen in a new window
Information in the press releases is current on the date of the announcement.
Product information, contact and other context are subject to change without prior notice.
